If you need a small tractor with robust capabilities. This is the one for you.
Engine
- Engine Model: 3A165LWH-U2
- Engine Gross Power: 24.5 hp (18.2 kW)
- Rated Speed: 2,600 rpm
- No. of Cylinders: 3
- Fuel Type: Diesel
- Aspiration: Natural
- Displacement: 87 cu. in. (1,647 cc)
- Fuel Tank Capacity: 6.6 gal. (25L)
Transmission
- Transmission Type: Hydrostatic
- Main Gear: Hydostatic
- No. Travel Speeds: Infinite/2R
- Min. Travel Speed: 0 mph (0 km/h)
- Max. Travel Speed: 10.7 mph (21.74 km.h)
Power Take-Off (PTO)
- PTO Type Transmission: Live
- PTO Power: 18.8 hp (14 kW)
- Rear PTO Speeds: 540 rpm
- Mid PTO Speeds: 2,000 rpm (Optional)
Brakes and Clutch
- Brake: Wet Disc Type
- Clutch: Dry Single
- Weight w/ Ag Tires w/ROPS: 2,260 lb. (1,025 kg)
Dimensions w/ Ag Tire
- Length w/ 3-point: 109.08 in. (2,790 mm)
- Width: 49.4 in. (1,256 mm)
- Height from Top of ROPS: 82.8 in. (2,103 mm)
- Wheelbase: 59.8 in. (1,520 mm)
- Ground Clearance: 13.4 in. (340 mm)
- Front Tread Ag Tires – Min: 38.1 in. (968 mm)
- Rear Tread Ag Tires – Min: 37.4 in. (951 mm)
- Min. Turning Radius w/Brake: 8.3 ft. (2.53 m)
Hydraulics
- Total Pump Flow: 11.3 gpm (42.9 L/min)
3-Point Hitch
- Standard Category: Category 1
- Lift Capacity, 24″” aft of hitch: 1,203 lbs (546 kg)
- Control Type: Position
Standard Equipment
- Hydrostatic Power Steering
- Rear PTO
- Headlights
- Safety Lights
- Cup Holder
- Illuminated Dashboard
- Wet Multi Disc Brakes
- Joystick Valve
- Adjustable Seat
- Parking Brake
- Cruise Control
Optional Equipment
- Rear Working Light
- Single Remote Hydraulic Valve
- Front Weight
- 7 Pin Socket
- Mid PTO
- 3rd Function Kit
- Sun Canopy
- Clevis Type Drawbar
Instrument Panel
- Digital Hour Meter
- Coolant Temperature Gauge
- Electrical Tachometer
- Fuel Gauge
- Engine Oil Pressure Light
- High Beam, Emergency Flasher, Direction Indicators
- Glow Plug Light
- Alternator Light
Available Tires
- Agriculture: Front 7-12; Rear 11.2-16
- Turf: Front 23X8.5-12; Rear 33X12.5-16.5
- Industrial: Front 23X8.5-12; Rear 12-16.5
